Ref.: 545911.270
PUMPMASTER 100 - 16:1 RATIO INK PNEUMATIC PUMP, 200 KG DRUM PNEUMATIC AUTOMATIC POWER RAM INDUCTOR PACKAGE
Ref.: 545911.270
PUMPMASTER 100 - 16:1 RATIO INK PNEUMATIC PUMP, 200 KG DRUM PNEUMATIC AUTOMATIC POWER RAM INDUCTOR PACKAGE
PM100 - 16:1 ratio ink pumps 545 011 mounted onto an air operated inductor plate for use with high viscosity fluids directly from 200 kg drum. The inductor system includes guide rods, drum retaining mechanism and a control box with the followin features: On/Off control of teh pump, Up/Down control of the Ram for easy drum exchange, Two independient air pressure regulators, one for the Pump and the other for the Powe Ram cylinders, Pump / Ram indepenent air pressure gauge, Empty drum shut-off safety feature, Automatic Vacuum release Instruction book: 854817.
About this product:
File 545911.270
Technical data
Documentation
More information
| Subtype | Pump on 200 kg drum pneumatic automatic power ram inductor package |
| Fluids | Others |
| Target product type | Shovel Intake Piston Pumps |
| Model | T-RAM |
| Application | Automotive Repair & Maintenance, Industrial Processes, Industrial Lubrication, Extrusion |
| Pressure ratio | 16:1 |
| Delivery | 11 kg/min (24,2 lb/min) |
| Delivery per cycle | 0,625 l (0,165 gal) |
| Maximum free flow delivery | 34 kg/min (75 lb/min) |
| Air pressure operating range | 1,5-7 bar (20-100 psi) |
| Air consumption | 1800 NL/min (63,5 scfm) |
| Maximum outlet pressure | 112 bar (1625 psi) |
| Air motor effective diameter | 250 mm (10 ") |
| Air motor stroke | 100 mm (4 ") |
| Air inlet | 1/2" BSP (F) / 1/2" NPT (F) |
| Fluid Inlet | 4" |
| Fluid inlet type | Chop-check |
| Fluid outlet | 1 1/2" BSP (F) / 1 1/2" NPT (F) |
| Wetted materials | Acetal, Viton, Carbon steel, Cast iron, Bronze, UHMWPE |
| Pump tube material | Carbon steel |
| Pump Mounting | 205 l (55 gal) drum bung mounted |
| Tube height | 538 mm (21 ") |
| Total height | 1253 mm (49,3 ") |
| Sound level | 80 dB |
| Weight | 93,5 kg (206 lb) |
Kit components
| Code | Product |
|---|---|
| 391001.270 | DOUBLE POST AIR OPERATED PUMP HOIST WITH INDUCTOR FOR INK PISTON PUMPS, 200 KG DRUMS |
| 545011 | PNEUMATIC PISTON INK PUMP, PUMPMASTER 100, PM100 - 16:1 |
