Ref.: 507782
INDIVIDUALLY ENCLOSED HOSE REEL, RM-12CL SERIES, 15 M, 1/2", WINDSCREEN WASHER / ADBLUE-DEF / DETERGENT
Ref.: 507782
INDIVIDUALLY ENCLOSED HOSE REEL, RM-12CL SERIES, 15 M, 1/2", WINDSCREEN WASHER / ADBLUE-DEF / DETERGENT
Corrosion resistant aluminium enclosure form a very rigid and stable structure, with light weight and attractive design. Fatigue resistant steel spring for years of durable performance and even load when pulling and recoiling the hose. Full port shaft and swivel for no restrictions. Spool mounted on two permanent lubricated and sealed ball bearings to reduce torque load on spring for smooth retraction and longer life. Large effective radial latching area for easier operation. Positionable mounting brackets to accommodate any method of mounting. Two large lateral service windows facilitate common maintenance operations. Hose reels with hose include 0,8 m inlet hose.system in polymer to reduce noise. Large service panel allows hose reel maintenance without dismounting it. Wide hose outlet aids rolling, reduces piling up and premature wear of the hose. Fatigue resistant steel spring for years of durable performance and even load when pulling and recoiling the hose. Spool mounted on two permanent lubricated and sealed ball bearings to reduce torque load on spring for smooth retraction and longer life.. Hose reels with hose include 0,8 m inlet hose. Model with 15 m 1/2" hose for WINDSCREEN WASHER / ADBLUE-DEF / DETERGENT. Instruction books: 850820 and 836823.
About this product:
File 507782
Technical data
Documentation
More information
| Compatible fluids | Coolant, Windscreen washer, AdBlue/DEF |
| Hose in diameter | 1/2" |
| Hose length | 15 m (49,21 ft) |
| Fluid Inlet | 1/2" BSP (M) |
| Fluid outlet | 1/2" BSP (M) |
| Working Pressure | 20 bar (290,08 psi) |
| Installation options | Floor, Wall, Ceiling, Tank |
| Bare reel part number | 507978 |
| Weight | 20,5 kg (45,2 lb) |
Models
| Code | Compatible fluids | Hose in diameter | Hose length | Working Pressure |
|---|---|---|---|---|
| 507782 | Coolant, Windscreen washer, AdBlue/DEF | 1/2" | 15 m (49,21 ft) | 20 bar (290,08 psi) |
| 507762 | Coolant, Windscreen washer, AdBlue/DEF | 1/2" | 10 m (32,81 ft) | 20 bar (290,08 psi) |
| 507503 | Waste oil | 5/8" | 6 m (19,69 ft) | -0,9 bar (-13,05 psi) |
| 507421 | Water | 3/8" | 15 m (49,21 ft) | 170 bar (2470 psi) |
| 507321 | Grease, Oil | 3/8" | 15 m (49,21 ft) | 280 bar (4060 psi) |
| 507311 | Grease, Oil | 3/8" | 18 m (59,06 ft) | 280 bar (4060 psi) |
| 507301 | Grease, Oil | 3/8" | 10 m (32,81 ft) | 280 bar (4060 psi) |
| 507300 | Grease, Oil | 1/4" | 10 m (32,81 ft) | 350 bar (5075 psi) |
| 507222 | Oil | 1/2" | 15 m (49,21 ft) | 160 bar (2320 psi) |
| 507212 | Oil | 1/2" | 18 m (59,06 ft) | 160 bar (2320 psi) |
| 507202 | Oil | 1/2" | 10 m (32,81 ft) | 160 bar (2320 psi) |
| 507122 | Air, Water, Coolant | 1/2" | 15 m (49,21 ft) | 15 bar (220 psi) |
| 507121 | Air, Water, Coolant | 3/8" | 15 m (49,21 ft) | 15 bar (220 psi) |
| 507101 | Air, Water, Coolant | 3/8" | 10 m (32,81 ft) | 15 bar (220 psi) |
