Electric pumps: flowstar-hv - 561610 - Product detail
SAMOA Industrial
Ref.: 561610
400 V AC HV HIGH PERFORMANCE ELECTRIC MOTOR PUMPS FOR OIL, FLOWSTAR SERIES, 70 L/MIN
Ref.: 561610
400 V AC HV HIGH PERFORMANCE ELECTRIC MOTOR PUMPS FOR OIL, FLOWSTAR SERIES, 70 L/MIN
High performance external gear pumps directly coupled to an electric motor with IP 55 protection for the transfer or distribution of large volumes of lubricants. Pump gears are manufactured in steel and pump body is manufactured in cast iron. All pumps include adjustable by-pass valve.
About this product:
File 561610
Technical data
Documentation
More information
| Compatible fluids | Oil |
| Maximum free flow delivery | 70 l/min (18,5 gal/min) |
| Delivery | 70 l/min (18,5 gal/min) |
| Maximum outlet pressure | 9,5 bar (137,75 psi) |
| Supply type | 400 V AC |
| Current | 4.3 A |
| Power | 1500 w |
