Electric pumps: polux - 684531 - Product detail
Ref.: 684531
24 V DC ROTARY VANE PUMPS FOR DIESEL, POLUX SERIES, 40 L/MIN
Ref.: 684531
24 V DC ROTARY VANE PUMPS FOR DIESEL, POLUX SERIES, 40 L/MIN
Self priming pumps with self-adjustable vanes. Pump body made of cast-iron with rustproof treatment, rotor of sintered steel and vanes of acetyl resin. The pump includes a by-pass valve and a built in filter with easy access for cleaning. The pump can be mounted vertically or horizontally, has a carrying handle and 2 m cable with crocodile clamps. Inlet / outlet connection: 1" BSP (F) or flange coupling. Maximum suction lift: 2,5 m. Electric DC motor with IP-55 protection, allows intermittent operation duty with maximum cycles of 30 minutes. On/off switch and fuse.
About this product:
File 684531
Technical data
Documentation
More information
Compatible fluids | Diesel |
Maximum free flow delivery | 40 l/min (10,6 gal/min) |
Delivery | 40 l/min (10,6 gal/min) |
Maximum outlet pressure | 0,8 bar (11,6 psi) |
Supply type | 24 V DC |
Current | 13 A |
Power | 200 w |
